Description

AOS 3.5 V5 FPV Frame Kit

The AOS 3.5 V5 FPV Frame Kit is a premium choice for drone enthusiasts looking to build a high-performance FPV racing or freestyle drone. This frame kit is engineered for durability and lightweight construction, making it ideal for both competitive racing and casual flying. With a 3.5-inch size, it strikes the perfect balance between agility and stability, allowing for tight maneuvers and smooth flights.

Crafted from high-quality materials, the AOS 3.5 V5 frame offers exceptional strength to withstand the rigors of aerial acrobatics. The design features ample space for your electronic components, ensuring easy installation and a clean build. Whether you’re a seasoned pilot or a newcomer to the FPV scene, this frame kit provides an excellent foundation for your next build. Elevate your flying experience with the AOS 3.5 V5 FPV Frame Kit and enjoy the thrill of aerial adventure.

Description

Discover the future of sub 250g FPV with the AOS 3.5 V5, engineered to revolutionize your freestyle experience. Designed with cutting-edge patent pending technology and premium materials, here s why the AOS 3.5 V5 is the ultimate choice for drone enthusiasts.

Features

Supports up to 3.5 Props

AOS X-Cell Anti-Vibration Technology

Up to two 25.5×25.5, or 20×20 mm stacks

155° FOV no props in view

Fully DJI O3 compatible (soft mount + ND filters)

Supports 19-20mm cameras (hard or soft mounted)

Reinforced 7075 Aluminium Camera Cage

Supports Lengthwise or Toilet Tank battery mounting

⌀9 – ⌀12mm motor mounting (supports all standard 3 – 4 motors)

27x21mm M2 GoPro Mounting Pattern

32mm Rear Standoff Spacing (compatible with all AOS 3.5 antenna mounts)

Specifications

Product Name: AOS 3.5 V5 Frame Kit

Frame wheelbase: 162mm

Frame Dimension: L133*W93*H30 mm

Arm Thickness: 4mm

Top Plate Thickness: 1.5mm

Bottom Plate Thickness: 1.5mm

Upper Plate Thickness: 2mm

Max Flight Stack Height: 20mm

Max VTX Height: 20mm

Motor Mounting: 9×9-φ2mm 12×12-φ2mm

Flight Stack Mounting: 20*20 Φ2mm 25.5*25.5 Φ2mm

VTX Mounting: 20*20 Φ2mm 25.5*25.5 Φ2mm

Weight: 68g

Compatible: DJI O3 air unit Vista HD system BLITZ Whoop 1.6W VTX

Packing List

1 x AOS 3.5 V5 Frame Kit

1 x TPU Parts

1 x Screw Bag

2 x Battery Strap

2 x Battery pads
