Happymodel 2.4g Omnidirectional  Antenna for ExpressLRS(ELRS) EP1 RX IPEX IPX U.FL Compatible with TBS Tracer

Enhance your drone s communication capabilities with the Happymodel 2.4g Omnidirectional Antenna, specifically designed for use with ExpressLRS (ELRS) EP1 receivers. This high-performance antenna is compatible with various connections, including IPEX IPX and U.FL, making it an excellent choice for integration with TBS Tracer systems and other compatible devices.

The omnidirectional design ensures that your drone maintains a strong and stable signal regardless of its orientation, allowing for uninterrupted control and reliable telemetry. With a frequency range optimized for 2.4GHz, this antenna minimizes signal loss and provides extended range, making it perfect for racing and long-distance flying.

Constructed with durable materials, the Happymodel antenna is built to withstand the rigors of outdoor use while maintaining a lightweight profile that won t hinder your drone s performance. Its easy installation process ensures that both novice and experienced pilots can quickly upgrade their setup for enhanced flight performance. Elevate your flying experience and stay connected with the Happymodel 2.4g Omnidirectional Antenna!



Happymodel 2.4g Omnidirectional  Antenna for ELRS EP1 RX IPEX IPX U.FL

SPECIFICATIONS:

• Frequency  (MHz)      2400.0
• Efficiency (dBi)    -0.89
• Gain (dBi)     2.23
• Efficiency (%)       81.46
• Directivity (dB)     5.12
• Peak Gain Position (Theta)   180.00
• Peak Gain Position (Phi)      330.00
• Efficiency ThetaPol (%)       20.90
• Efficiency PhiPol (%)   60.56
• Upper Hem. Efficiency (%)  39.93
• Lower Hem. Efficiency (%) 41.54
• Connector IPEX IPX U.FL
• Antenna width 52mm
• Antenna length 40mm 90mm(optional)

• PACKAGE INCLUDES:

  • 1 x Happymodel 2.4g Omnidirectional  Antenna for ELRS EP1 RX IPEX IPX U.FL
